Page 6 - Patch Panel

Patch Panels

P197F

Cat.5e patch panel.

Patch Panels
Parameter
Meet ISO/IEC 11801,TIA/EIA568C.
British type.
Fit for wires AWG22-26.
Plug omsertopm life 200 cycles.
Plug insertion life 750 cycles Min.
Dielectric strength:When applied AC 750V or DC
1000V 1 minute between adjacent terminal NO
change.
Material:Using PC/ABS for cover,PC for module,
phosphor bronze for IDC wire post.
Krone IDC.
Order Information:

Item No. Description
P197-16F 19".lu,16 ports
P197-24F 19".lu,24 ports
P197-48F 19".lu,48 ports

P197R

Cat.6 patch panel.

Parameter
Meet ISO/IEC 11801,TIA/EIA568C.
British type.
Have connector & cable management,convenient
for using High-quality guaranteed.
Fit for wires AWG22-26.
Plug omsertopm life 200 cycles.
Plug insertion life 750 cycles Min.
Dielectric strength:When applied AC 750V or DC
1000V 1 minute between adjacent terminal NO
change.
Material:Using PC/ABS for cover,PC for module,
phosphor bronze for IDC wire post.
Krone IDC.

Order Information:
Item No. Description
P197-16R 19".lu,16 ports
P197-24R 19".lu,24 ports
P197-48R 19".lu,48 ports
