Page 15 - Wall Mount Cabinets

VA DOUBLE SECTION

Feature Wall Mount Cabinets
Disassembled and small packaging, easy to deliver and carry.
Special design front and back frames are with good stability.
16 screws are needed to assemble the whole enclosure. It will
take only 10 minutes to assemble the enclosure by one person.
Front door is with corrective structure to avoid door dropping.
Opening direction could be changed easily.
Cable entries are available on top, bottom and back of
enclosure, suitable for different places.
The patented cable entries are adjustable and with the design
to prevent wires from scratching.
Opening direction of enclosures can be changed quickly.
Automatic locking ensures safety and reliability.
Maximum Loading capacity: 30kgs.

Main Part

S/N Specification Qty Material Surface Finish Remark
1 Back frame 1 SPCC t1.0 Powder coated ----
2 Top cover 1 SPCC t1.0 Powder coated ----
3 Bottom 1 SPCC t1.0 Powder coated ----
4MM toughed glass
4 Front door 1 door/ SPCCt1.0 Powder coated Small lock
5 19 '' rails frame 2 SPCC t1.5 Powder coated ----
6 Side panel 2 SPCC t1.0 Powder coated ----

Specification

Capacity Width Depth(D) Height(H) Disassembled packing Assembled packing
Model N o. (U) (mm) (mm) (mm) dimension(MM) dimension(MM)
VA.5406. ■00 450 570*280*440 550*460*350
6 540 327
VA.5606. ■00 600 570*310*545 550*610*350
VA.5409. ■00 450 600*265*490 550*460*480
9 540 460
VA.5609. ■00 600 600*310*530 550*610*480
VA.5412. ■00 450 600*265*625 550*460*610
12 540 593
VA.5612. ■00 600 600*290*625 550*610*610
VA.5415. ■00 450 600*265*760 550*460*750
15 540 725
VA.5615. ■00 600 600*290*760 550*610*750
